Bucket
Bucket Capacity - 1 cu yd (1 cu m)
Bucket Width - 7 ft (2 m)
Dump Clearance at Max Raise - 10 ft (3 m)
Dimensions
Height Top of Cab - 9 ft (3 m)
Hinge Pin Max Height - 12 ft (4 m)
Length with Bucket on Ground - 17 ft (5 m)
Reach at Max Lift and Dump - 4 ft (1 m)
Wheelbase - 8 ft (2 m)
Width Over Tires -6 ft (2 m)
Engine
Displacement - 199 cu in (3,261 cu cm)
Engine Model - 4D95L
Gross Power - 55 hp (41 kw)
Number of Cylinders - 4
Operating Specifications
Fuel Capacity - 17 gal (63 l)
Operating Weight - 12,566 lbs (5,700 kg)
Tire Size - 17.5/65 20-10PR
Turning Radius - 16 ft (5 m)
Transmission
Max Speed - Forward - 18 mph (29 kph)
Max Speed - Reverse - 19 mph (30 kph)
Number of Forward Gears - 3
Number of Reverse Gears - 3
